Footprints for DSBGA, QFN, and SON packages have no suffix and will simply be xxxxxx. The suffixes 'L' and 'M' indicate Least and Most real estate on the PCB and the name with no suffix indicates Nominal density on the PCB. The footprints available in three sizes (based on the IPC-7351 standard for the Least, Nominal, and Most) follow this naming convention: xxxxxx for Nominal, xxxxxx-L for Least, and xxxxx-M for Most. It is anticipated that this free download service will save TI's customers significant time. Providing components based on parametric data through the Ultra Librarian Reader will allow TI customers to reliably create consistent quality CAD entities to an established standard with minimal effort. In addition, the components (both symbol and footprint) can be modified to meet a user-defined standard using a purchased upgrade to the Ultra Librarian. The UL Reader is a subset of the Ultra Librarian toolset that can generate, import, and export components and their attributes in virtually any EDA CAD/CAE format.įootprints generated by the UL Reader are based on the IPC-7351 specification (with the exception of DSBGA, QFN, and SON packages which have one footprint only).
The reader is available for free download ( ZIP: 77MB). Altium PCAD (importable by Altium Designer)īoth PCB footprints and schematic symbols are available for download in a vendor neutral format which can then be exported to the leading EDA CAD/CAE design tools using the Ultra Librarian Reader.Step 3: - On the search results page, click on the desired part and open the file to start the Ultra Librarian software.ĬAD/EDA schematic symbols and PCB footprints are available in the following formats: Step 2: - Enter the desired part in the search box above, then click the search button. Step 1: - Before installing a new version of UltraLibrarian software ZIP: 77MB you mustĮnsure that you have uninstalled all previous versions of UltraLibrarian on your local machine.ĭelete previous versions of UltraLibrarian directory (c:\UltraLibrarian) completely on your local machine.ĭownload and run the executable in Administrator mode and install the UltraLibrarian software in c:/UltraLibrarian on your local machine. Search for symbol and footprints, enter a Texas Instruments part number first four characters below. have collaborated together to provide TI customers with schematic symbols and PCB layout footprints for TI products. Texas Instruments and Accelerated Designs Inc.
